HV-1000 type micro hardness tester is the basic type of micro hardness tester, the machine uses LCD display, for hardness scale HV or HK stall test force dwell time is selected via the operator panel, the light source brightness for stepless regulation. After the operation, the eyepiece can be measured D1, D2 value direct input, hardness values will be displayed on the LCD monitor.


Measuring range	5-3000HV
Test force	0.09807、0.2452、0.4904、0.9807、1.961、2.942、4.904、9.807N
Sample maximum allowable height	90mm
Pressure head center to wall distance	120mm
The minimum detection unit	0.25μm
Measurement System Magnification	400×，100×
Dimensions	530×290×490mm
Power supply	AC220V，50/60Hz
Weight	40kg



The standard used:JJG 260-1991 micro hardness tester

Owned material: Steel, non-ferrous metal, micro and thin shaped components。

Industry: Metal processing, electronics industry, mold parts, the watch industry

Test Type: Knoop hardness



◆ instrument uses a unique, sophisticated design on the mechanical, optical, light, make indentation image clearer, more precise measurements.

◆ The machine is equipped with 10x and 40x objective lens, 10x eyepiece micrometer.

◆ on the screen can display test force, test methods, test force dwell time, number of measurements, etc., when operating as long as the input from the membrane keyboard indentation diagonal length, built-in calculator automatically calculates the hardness value and displayed on the LCD screen simple look-up table cumbersome.

◆ In the light source is a halogen lamp life 100,000 hours
